Product Overview

RefComp SB4C-120E

Name: RefComp SB4C-120E
Brand: RefComp
SKU: SB4C-120E
Availability: InStock

SBC 2-Stage Series

Model: SB4C-120E

Compressor Type: Piston

Cylinders: 4

Product Model

Details

Motor Size

HP: 12

Kw: 9

Displacement (m3/h )

50Hz: LP=43 / HP=27.6

60Hz: LP=51.5 / HP=33.2

Electrical Charecteristics

Standard Electrical Supply: Part Wind (PW): 400V/3/50Hz ~ 460V/3/60Hz

Max. Starting Current (A): (PW/DOL) 74/123

Max Running Current (A): 27

Service Valves

Discharge (mm) / Inches: 28mm (1-1/8")

Suction (mm) / Inches: 35mm (1-3/8")

Additional Info

Cylinders: 4

Lubrication

Lubrication: Pump

Standard Oil: POE32

Oil charge (Litres): 3.7L

Competitors

Comparison

Bitzer

S4G-12.2Y

Bock

Frascold

Dorin

Copeland
