Product Overview

RefComp SW3L-13000

Name: RefComp SW3L-13000
Brand: RefComp
SKU: SW3L-13000
Availability: InStock

SW3 Screw Series

Model: SW3L-13000

Compressor Type: Screw

Cylinders:

Product Model

Details

Motor Size

HP: 130

Kw: 98

Displacement (m3/h )

50Hz: 445

60Hz: 534

Electrical Charecteristics

Standard Electrical Supply: Star/Delta: 400V/3/50Hz ~ 460V/3/60Hz

Max. Starting Current (A): (Y/Δ) 354/1155

Max Running Current (A): 210

Service Valves

Discharge (mm) / Inches: 80mm (3-1/8")

Suction (mm) / Inches: 92.5mm (3-5/8")

Additional Info

Capacity Regulation: 25/50/75/100% (4 Step) or 25~100% Stepless

Lubrication

Lubrication: Differential
