Product Overview

RefComp SW3L-7000

Name: RefComp SW3L-7000
Brand: RefComp
SKU: SW3L-7000
Availability: InStock

SW3 Screw Series

Model: SW3L-7000

Compressor Type: Screw

Cylinders:

Product Model

Details

Motor Size

HP: 70

Kw: 52

Displacement (m3/h )

50Hz: 237

60Hz: 284

Electrical Charecteristics

Standard Electrical Supply: Star/Delta: 400V/3/50Hz ~ 460V/3/60Hz

Max. Starting Current (A): (Y/Δ) 139/459

Max Running Current (A): 117

Service Valves

Discharge (mm) / Inches: 54mm (2-1/8")

Suction (mm) / Inches: 67mm (2-5/8")

Additional Info

Capacity Regulation: 25/50/75/100% (4 Step) or 25~100% Stepless

Lubrication

Lubrication: Differential

Competitors

Comparison

Bitzer

HSN7461-70

Bock

Frascold

Dorin

Copeland
